The CSTAR CSQD-15 1.5 Ton Diesel Forklift Truck is rated for 1,500 kg at a 500 mm load center with a standard lift height of 3,000 mm.
At 1,090 mm wide with a 1,950 mm turning radius, the CSQD-15 sits at the compact end of CSTAR’s diesel counterbalance forklift range.
CSQD-15 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Brand / Model | CSTAR CSQD-15 |
| Capacity | Rated Capacity | 1,500 kg |
| Capacity | Load Center | 500 mm |
| Lifting | Lift Height | 3,000 mm |
| Lifting | Free Lift | 100 mm |
| Dimensions | Length with / without Forks | 3,180 / 2,260 mm |
| Dimensions | Width | 1,090 mm |
| Dimensions | Mast Lowered Height | 1,990 mm |
| Dimensions | Overhead Guard Height | 2,090 mm |
| Chassis | Wheelbase | 1,400 mm |
| Chassis | Ground Clearance | 110 mm |
| Maneuverability | Turning Radius | 1,950 mm |
| Maneuverability | Aisle Width | 3,630 mm |
| Lifting | Mast Tilt | 6° / 12° |
| Performance | Lift Speed, No / Full Load | 500 / 480 mm/s |
| Performance | Travel Speed, No / Full Load | 15 / 14 km/h |
| Performance | Gradeability | 20% |
| Weight | Service Weight | 2,900 kg |
| Tires | Front Tire | 6.5-10-10PR Pneumatic |
| Tires | Rear Tire | 5.00-8-10PR Pneumatic |
| Engine | Engine Model | Xinchai NC485BPG |
| Electrical | Battery | 12 V / 80 Ah |
| Fuel System | Fuel Tank | 40 L |
Compact Dimensions Are the Main CSQD-15 Difference
The CSQD-15 is 1,090 mm wide with a
1,950 mm turning radius. For sites where a diesel forklift is
required but access width and turning space are limited, these two dimensions
are more useful than comparing rated capacity alone.
Check Passage Height as Well as Width
The mast-lowered height is 1,990 mm, while the overhead guard
height is 2,090 mm. If the truck needs to pass through doors,
covered loading areas or low-clearance routes, use the taller fixed point when
checking the available opening and leave practical clearance.
Common Ordering Questions
Will the CSQD-15 fit through a 1.2-meter-wide access?
The listed truck width is 1,090 mm, but access should not be checked from width
alone. Allow operating clearance and check the complete route, including turns,
doorway height and the load or fork position.
Does the 1,950 mm turning radius tell me the required aisle width?
No. The load and pallet length also affect the space needed to turn and stack.
The specification lists a 3,630 mm aisle width for the base
truck configuration.
Send the maximum load weight, load dimensions, required lift height,
working aisle or access dimensions and destination country.
