The CSTAR CSQD-40 4 Ton Diesel Forklift Truck is rated for 4,000 kg at a 500 mm load center with a standard lift height of 3,000 mm.
The truck uses a Xinchai A495BPG diesel engine and has a listed service weight of 4,950 kg.
CSQD-40 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Brand / Model | CSTAR CSQD-40 |
| Capacity | Rated Capacity | 4,000 kg |
| Capacity | Load Center | 500 mm |
| Lifting | Lift Height | 3,000 mm |
| Lifting | Free Lift | 150 mm |
| Dimensions | Length with / without Forks | 4,000 / 2,930 mm |
| Dimensions | Width | 1,290 mm |
| Dimensions | Mast Lowered Height | 2,130 mm |
| Dimensions | Overhead Guard Height | 2,180 mm |
| Chassis | Wheelbase | 1,900 mm |
| Chassis | Ground Clearance | 140 mm |
| Maneuverability | Turning Radius | 4,750 mm |
| Lifting | Mast Tilt | 6° / 12° |
| Performance | Lift Speed, No / Full Load | 420 / 380 mm/s |
| Performance | Travel Speed | 22 / 22 km/h |
| Performance | Gradeability | 20% |
| Weight | Service Weight | 4,950 kg |
| Tires | Tire Configuration | 250-15 / 650-10 Pneumatic |
| Engine | Engine Model | Xinchai A495BPG |
| Electrical | Battery | 12 V / 80 Ah |
| Fuel System | Fuel Tank | 55 L |
Check Width and Height Together
The CSQD-40 is 1,290 mm wide, but width is only one part of a
site-fit check. The mast is 2,130 mm high when lowered and the
overhead guard is 2,180 mm high. For doorways, covered loading
areas or other height-restricted routes, use the highest fixed point of the truck
and leave practical clearance rather than matching the opening to the specification exactly.
What the 20% Gradeability Figure Tells You
The specification lists 20% gradeability. Use this as a machine
performance reference, not as a blanket approval for every ramp. Surface grip,
ramp length, load condition and the transition at the top and bottom of the ramp
still matter when checking a real site.
Common Ordering Questions
Which height should I use when checking a doorway?
Check both figures. The mast-lowered height is 2,130 mm and the overhead guard
height is 2,180 mm. The taller fixed point normally controls the minimum passage
height, and additional clearance should be allowed for uneven ground and operating conditions.
Does 20% gradeability mean the CSQD-40 can use any 20% ramp at full load?
No. The gradeability figure is a performance specification. Actual ramp use also
depends on load condition, traction, surface quality, ramp length and site layout.
Send the load weight, required lift height, doorway or access dimensions,
ramp conditions and destination country.
