The CSTAR CSQD-50 5 Ton Diesel Forklift Truck is rated for 5,000 kg at a 600 mm load center with a standard lift height of 3,000 mm.
The truck has a listed service weight of 8,400 kg, a width of 1,970 mm and a CA6110 diesel engine.
CSQD-50 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Capacity | Rated Capacity | 5,000 kg |
| Capacity | Load Center | 600 mm |
| Lifting | Lift Height | 3,000 mm |
| Lifting | Free Lift | 210 mm |
| Dimensions | Length with / without Forks | 4,690 / 3,510 mm |
| Dimensions | Width | 1,970 mm |
| Dimensions | Mast Lowered Height | 2,450 mm |
| Dimensions | Overhead Guard Height | 2,500 mm |
| Chassis | Wheelbase | 2,250 mm |
| Chassis | Ground Clearance | 230 mm |
| Maneuverability | Turning Radius | 4,080 mm |
| Maneuverability | Aisle Width | 5,230 mm |
| Lifting | Mast Tilt | 6° / 12° |
| Performance | Lift Speed, No / Full Load | 530 / 500 mm/s |
| Performance | Travel Speed, No / Full Load | 29 / 24 km/h |
| Performance | Gradeability | 15% |
| Weight | Service Weight | 8,400 kg |
| Tires | Tires | 4 Front / 2 Rear Pneumatic, 8.25-15NHS |
| Engine | Engine | CA6110 |
| Electrical | Battery | 2 × 12 V / 80 Ah |
| Fuel System | Fuel Tank | 160 L |
The Step from 3–4 Ton to 5 Ton Is More Than Capacity
The CSQD-50 moves into a noticeably larger chassis class. Its width is
1,970 mm, the turning radius is 4,080 mm,
and the listed aisle width is 5,230 mm.
Buyers moving up from a 3 or 4 ton forklift should check the working area before
treating 5 ton as a simple capacity upgrade.
Where the CSQD-50 Sits in the Heavy-Duty Range
The CSQD-50 is the point to compare when a 3–4 ton truck no longer provides enough
rated capacity, but regular loads do not justify moving directly into the 7 ton class.
It keeps the rated capacity at 5,000 kg while avoiding the additional size and service
weight of the larger heavy-duty models.
Common Ordering Questions
Can the CSQD-50 work in the same area as a 3 or 4 ton forklift?
Not necessarily. The CSQD-50 is 1,970 mm wide, has a 4,080 mm turning radius
and a listed aisle width of 5,230 mm. Compare those figures with the current
truck and the actual site before moving up in capacity.
When should I choose the CSQD-50 instead of moving to a 7 ton forklift?
If regular loads remain within the 5,000 kg class with enough operating margin,
moving to a 7 ton truck adds a larger and heavier machine without necessarily
adding useful capacity for the job.
Send the maximum regular load, load dimensions, required lift height,
available turning area and destination country.
