The CSTAR CSQD-80 8 Ton Diesel Forklift Truck is rated for 8,000 kg at a 600 mm load center with a standard lift height of 3,000 mm.
The CSQD-80 has a service weight of 10,800 kg, a width of 2,100 mm and a CA6110 diesel engine.
CSQD-80 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Capacity | Rated Capacity | 8,000 kg |
| Capacity | Load Center | 600 mm |
| Lifting | Lift Height | 3,000 mm |
| Lifting | Free Lift | 200 mm |
| Dimensions | Length with / without Forks | 5,175 / 3,830 mm |
| Dimensions | Width | 2,100 mm |
| Dimensions | Mast Lowered Height | 2,870 mm |
| Dimensions | Overhead Guard Height | 2,550 mm |
| Chassis | Wheelbase | 2,500 mm |
| Chassis | Ground Clearance | 250 mm |
| Maneuverability | Turning Radius | 4,540 mm |
| Lifting | Mast Tilt | 10° / 12° |
| Performance | Lift Speed | 350 / 330 mm/s |
| Performance | Travel Speed | 26 / 20 km/h |
| Performance | Gradeability | 15% |
| Weight | Service Weight | 10,800 kg |
| Tires | Tires | 4 Front / 2 Rear, 8.25-20NHS Pneumatic |
| Engine | Engine | CA6110 |
| Electrical | Battery | 2 × 12 V / 80 Ah |
| Fuel System | Fuel Tank | 160 L |
8 Ton or 10 Ton?
If regular loads stay within the 8 ton class with enough working margin, the CSQD-80
avoids moving straight to the larger 10 ton chassis. Compared with the CSQD-100,
the CSQD-80 is 145 mm narrower and 1,610 kg lighter in service weight, so the difference
is not only rated capacity — it also affects machine size and site handling.
The 600 mm Load Center Still Matters
The 8,000 kg rating is based on a 600 mm load center.
Long steel, machinery or other loads with a center of gravity farther forward should
be checked using their actual dimensions and lifting position rather than the rated
capacity alone.
Common Ordering Questions
When should I move from an 8 ton forklift to a 10 ton forklift?
Move up when regular loads are too close to the 8 ton rated capacity or the actual
load geometry reduces the usable capacity margin. If 8,000 kg already covers the
normal load with margin, the larger 10 ton chassis may add size without adding useful capacity.
Is a long 8,000 kg load automatically within the CSQD-80 rating?
No. The rated capacity is specified at a 600 mm load center. For long or irregular
loads, provide the weight, dimensions and lifting position so the actual configuration
can be checked.
Send the maximum load weight, load dimensions, required lift height,
available working space and destination country.
