The CSTAR CSGL-S360 Mini Skid Steer Loader has a 200 kg rated load, a 0.1 m³ bucket and a listed operating weight of only 880 kg.
Within this group of CSTAR mini loaders, the S360 sits at the lightweight end of the range.Its role is straightforward: a small wheeled machine for light material-handling work rather than higher-capacity loading.
CSGL-S360 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Model | CSGL-S360 |
| Performance | Operating Weight | 880kg |
| Performance | Bucket Capacity | 0.1m³ |
| Performance | Climbing Ability | 25° |
| Performance | Maximum Breakout Force | 3.5KN |
| Performance | Rated Load | 200kg |
| Performance | Maximum Load | 300kg |
| Performance | Travel Speed | 0-6km/h |
| Dimensions | Vehicle Width | 1000mm |
| Hydraulic System | Rated Pressure | 16Mpa |
| Bucket | Bucket Width | 1050mm |
| Working Range | Max Loading Height | 1680mm |
| Working Range | Max Dumping Height | 1367mm |
| Working Range | Max Operating Height | 2400mm |
| Working Range | Height to Bucket Pin | 1840mm |
| Working Range | Max Height Bucket Dump Angle | 63° |
| Dimensions | Min Height | 1300mm |
| Chassis | Departure Angle | 21° |
| Chassis | Ground Clearance | 130mm |
| Working Range | Dumping Distance | 258mm |
| Chassis | Wheelbase | 710mm |
| Dimensions | Overall Dimensions | 2130*1050*1300mm |
| Dimensions | Length Including Bucket | 2130mm |
| Dimensions | Length Excluding Bucket | 1726mm |
| Tires | Tire Model | 18*8.5-8 |
| Power System | Brand | Lithium electricity/KOOP/Rato/B&S |
| Power System | Model | Lead-acid battery/192FH/R420D/XR13.5 |
| Power System | Rated Power | 6kw,72V,125ah/7.6(7)/7.9/9.92kw |
| Engine | Cylinder | 1 |
| Engine | Intake Method | Natural inhalation |
| Engine | Emission Standard | EPA/ERUO5 |
| Engine | Fuel Tank Capacity | 5L |
880 kg Lightweight Wheeled Platform
With a listed operating weight of 880 kg and rated load of
200 kg, the S360 occupies the lightweight, light-duty end of this CSTAR mini skid steer group.
It is a different proposition from the S460, S480 and S25, which move progressively further toward higher rated capacity.
Request a CSGL-S360 Quote
Send the material, typical load, working surface, access dimensions and destination country.
