The CSTAR CSGL-T470 Mini Track Loader has a 240 kg rated load, a 0.12 m³ bucket and a 5.1 kN maximum breakout force.
On this model, the breakout-force figure is particularly useful when comparing bucket work rather than judging the machine by rated load alone.
CSGL-T470 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Model | CSGL-T470 |
| Performance | Operating Weight | 1,291 kg |
| Performance | Bucket Capacity | 0.12 m³ |
| Performance | Climbing Ability | 25° |
| Performance | Maximum Breakout Force | 5.1 kN |
| Performance | Rated Load | 240 kg |
| Performance | Maximum Load | 400 kg |
| Performance | Travel Speed | 0–5 km/h |
| Performance | Vehicle Width | 1,024 mm |
| Hydraulic System | Rated Pressure | 16 MPa |
| Bucket | Bucket Width | 1,050 mm |
| Working Range | Maximum Loading Height | 2,024 mm |
| Working Range | Maximum Dumping Height | 1,376 mm |
| Working Range | Maximum Operating Height | 2,561 mm |
| Working Range | Height to Bucket Pin | 2,071 mm |
| Working Range | Bucket Dump Angle at Maximum Height | 63° |
| Dimensions | Minimum Height | 1,300 mm |
| Chassis | Departure Angle | 25° |
| Chassis | Ground Clearance | 195 mm |
| Working Range | Dumping Distance | 231 mm |
| Track | Track Contact Length | 1,300 mm |
| Dimensions | Overall Dimensions | 2337 × 1050 × 1300 mm |
| Dimensions | Length Including Bucket | 2,337 mm |
| Dimensions | Length Excluding Bucket | 1,750 mm |
| Track | Track Model | 180 × 72 × 35 |
| Engine | Engine Brand Options | Rato / KOOP / B&S |
| Engine | Engine Model Options | R740 / 292F / Vanguard23 |
| Engine | Rated Power | 16.8 / 15 / 17 kW |
| Engine | Cylinder | 2 |
| Engine | Intake Method | Naturally Aspirated |
| Engine | Emission Standard | EPA / ERUO5 |
| Engine | Fuel Tank Capacity | 21 L |
Look at Breakout Force, Not Only Rated Load
The T470 is rated at 240 kg, but the bucket system is specified with a
5.1 kN maximum breakout force.
For work that involves filling the bucket from a material pile, breakout force gives an additional performance reference that rated load alone does not show.
