The CSTAR CSGL-T490 Mini Track Loader has a 250 kg rated load, a 0.1 m³ bucket and a 580 mm dumping distance.
That forward dumping reach is the specification to check when material needs to clear the edge of a bin, cart or other receiving point.
CSGL-T490 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Model | CSGL-T490 |
| Performance | Operating Weight | 1,305 kg |
| Performance | Bucket Capacity | 0.1 m³ |
| Performance | Climbing Ability | 25° |
| Performance | Maximum Breakout Force | 4.5 kN |
| Performance | Rated Load | 250 kg |
| Performance | Maximum Load | 350 kg |
| Performance | Travel Speed | 0–5 km/h |
| Performance | Vehicle Width | 1,089 mm |
| Hydraulic System | Rated Pressure | 16 MPa |
| Bucket | Bucket Width | 1,150 mm |
| Working Range | Maximum Loading Height | 1,700 mm |
| Working Range | Maximum Dumping Height | 1,402 mm |
| Working Range | Maximum Operating Height | 2,489 mm |
| Working Range | Height to Bucket Pin | 1,900 mm |
| Working Range | Bucket Dump Angle at Maximum Height | 63° |
| Dimensions | Minimum Height | 1,300 mm |
| Chassis | Departure Angle | 15° |
| Chassis | Ground Clearance | 220 mm |
| Working Range | Dumping Distance | 580 mm |
| Track | Track Contact Length | 1,330 mm |
| Dimensions | Overall Dimensions | 2535 × 1150 × 1300 mm |
| Dimensions | Length Including Bucket | 2,535 mm |
| Dimensions | Length Excluding Bucket | 2,100 mm |
| Track | Track Model | 180 × 72 × 45 |
| Power System | Power Options | Lithium Electric / KOOP / Rato / B&S |
| Power System | Model Options | Lithium Iron Phosphate / 292F / R740 / Vanguard23 |
| Power System | Rated Power | 8 kW, 72V, 200Ah / 15 kW / 16.8 kW / 17 kW |
| Engine | Cylinder | 2 |
| Engine | Intake Method | Naturally Aspirated |
| Engine | Emission Standard | EPA / EURO 5 |
| Engine | Fuel Tank Capacity | 10 L |
580 mm Forward Dumping Reach
The T490 has a listed 580 mm dumping distance, paired with a
1,402 mm maximum dumping height.
When the bucket needs to clear the side or edge of a receiving point, these two dimensions should be checked together.
