The CSTAR CSGL-S480 Mini Skid Steer Loader carries a 350 kg rated load while keeping the machine height to 1,300 mm.
This load-and-height combination places the S480 above CSTAR’s lighter 180–300 kg mini skid steer models in rated capacity without moving into a full size skid steer platform.
CSGL-S480 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Model | CSGL-S480 |
| Performance | Operating Weight | 1240kg |
| Performance | Bucket Capacity | 0.1m³ |
| Performance | Climbing Ability | 25° |
| Performance | Maximum Breakout Force | 4.5KN |
| Performance | Rated Load | 350kg |
| Performance | Maximum Load | 450kg |
| Performance | Travel Speed | 0-6km/h |
| Dimensions | Vehicle Width | 1110mm |
| Hydraulic System | Rated Pressure | 16Mpa |
| Bucket | Bucket Width | 1050mm |
| Working Range | Max Loading Height | 1680mm |
| Working Range | Max Dumping Height | 1370mm |
| Working Range | Max Operating Height | 2290mm |
| Working Range | Height to Bucket Pin | 1835mm |
| Working Range | Max Height Bucket Dump Angle | 63° |
| Dimensions | Min Height | 1300mm |
| Chassis | Departure Angle | 18° |
| Chassis | Ground Clearance | 125mm |
| Working Range | Dumping Distance | 261mm |
| Chassis | Wheelbase | 760mm |
| Dimensions | Overall Dimensions | 2194*1050*1300mm |
| Dimensions | Length Including Bucket | 2194mm |
| Dimensions | Length Excluding Bucket | 1770mm |
| Tires | Tire Model | 18*8.5-8 |
| Engine | Brand | Yanmar/Kubota |
| Engine | Model | 3TNV80/D1105 |
| Engine | Rated Power | 15.2(17.8)/17.1kw |
| Engine | Cylinder | 3 |
| Engine | Intake Method | Naturally aspirated |
| Engine | Emission Standard | EPA/ERUO5 |
| Engine | Fuel Tank Capacity | 13L |
350 kg Rated Load at 1,300 mm Machine Height
The S480 combines a 350 kg rated load with a
1,300 mm minimum machine height. That puts more rated loading capacity into the same low-height class used by several smaller CSTAR mini loaders.
Request a CSGL-S480 Quote
Send the typical load, available height, working surface, required dumping height and destination country.
