The CSTAR CSGL-S370 Mini Skid Steer Loader has a 180 kg rated load, a 0.07 m³ bucket and an operating weight of 1,000 kg.
At 180 kg rated capacity, the S370 sits at the light-duty end of this CSTAR mini skid steer range. It is the model to compare when the daily job does not justify moving up to the 300–450 kg rated-load machines.
CSGL-S370 Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| General | Brand / Model | CSTAR CSGL-S370 |
| Performance | Operating Weight | 1,000 kg |
| Performance | Rated Load | 180 kg |
| Performance | Maximum Load | 210 kg |
| Bucket | Bucket Capacity | 0.07 m³ |
| Bucket | Bucket Width | 1,050 mm |
| Performance | Maximum Breakout Force | 3.5 kN |
| Performance | Travel Speed | 0–6 km/h |
| Performance | Climbing Ability | 25° |
| Hydraulic System | Rated Pressure | 16 MPa |
| Dimensions | Vehicle Width | 982 mm |
| Dimensions | Overall Dimensions | 2138 × 1050 × 1300 mm |
| Dimensions | Length Including Bucket | 2,138 mm |
| Dimensions | Length Excluding Bucket | 1,528 mm |
| Working Range | Maximum Loading Height | 1,840 mm |
| Working Range | Maximum Dumping Height | 1,373 mm |
| Working Range | Maximum Operating Height | 2,030 mm |
| Working Range | Height to Bucket Pin | 1,925 mm |
| Working Range | Bucket Dump Angle at Maximum Height | 63° |
| Chassis | Departure Angle | 22° |
| Chassis | Ground Clearance | 122 mm |
| Working Range | Dumping Distance | 83 mm |
| Chassis | Wheelbase | 650 mm |
| Tires | Tire Model | 18 × 8.5-8 |
| Engine | Engine Options | B&S XR13.5 / KOOP 192FH / Rato R420D |
| Engine | Rated Power | 9.92 / 7.6 (7) / 7.9 kW |
| Engine | Cylinder | 1 |
| Engine | Intake Method | Naturally Aspirated |
| Engine | Emission Standard | EPA / ERUO5 |
| Engine | Fuel Tank Capacity | 19 L + 6.6 L |
A 180 kg Light-Duty Mini Skid Steer
The S370 is rated for 180 kg. That places it below the 200 kg, 300 kg, 350 kg and 450 kg models in this group and makes its role straightforward: light material handling where moving up to a larger loader is unnecessary.
Request a CSGL-S370 Quote
Send the material, typical load, working area dimensions, required dumping height and destination country.
